The AWY-1000SM is a professional tracked flail mower featuring a 195F diesel engine, 100cm cutting width, 500m remote control, and up to 55° gradeability.
The AWY-1000SM is a diesel-powered tracked remote control flail mower designed for large-area and demanding mowing operations. Equipped with a YARMAX 195F diesel engine, 100cm flail cutting system, dual 850W brushless walking motors, and hydraulic lifting, it combines wide-area coverage with remote operation for grasslands, farms, slopes, commercial green spaces, and photovoltaic sites.
Remote Control Operation
55° Maximum Gradeability
100cm Cutting Width
Review the key specification differences below and choose the most suitable model for your inquiry.
| Specification Field | AWY-1000SM |
|---|---|
| Engine Type | Gasoline LONCIN 459CC EPA Euro V / Diesel YARMAX 195F |
| Cutting Width | 100 cm |
| Cutting Height | 2 - 20 cm remote control adjustment |
| Walking Motor | 850W Brushless Motor |
| Machine Size | 1650 x 1120 x 760 mm |
| Package Size | 1750 x 1240 x 920 mm |
| Machine Weight | 354 kg |
| Package Weight | 427 kg |
| Starting Method | Key start and stop |
| Walking Speed | 3 - 5 km/h |
| Gradeability | 55° |
| Power | Gasoline LONCIN 459CC / Diesel YARMAX YM195F |
| Fuel Tank Capacity | 6.5 L / 5.5 L |
| Oil Capacity | 1.1 L / 1.65 L |
| Fuel Consumption | 1.2 L/h |
| Track Width | 150 mm |
| Mowing Efficiency | 1500 m2/h |
| Lifting Method | Remote control hydraulic lift |
| Knife Speed | 2500 - 3000 r/min |
Review product structure, components and close-up details for this mower model.
See the AWY-1000SM in real vegetation management and mowing applications.
Available engine or configuration options should be confirmed according to the selected model and order requirement.
100cm Flail Cutting System
Electric / Recoil Starting
Remote Start & Stop
Review current product questions and answers for AWY-1000SM.
